Behringer X32 Compact 40-channel Digital Mixer

Live Digital Mixing Has Never Been Easier!

Behringer's X32 Compact digital mixer packs everything you need to easily mix and record a live show into a svelte, roadworthy package. But with its amazing-sounding Midas-designed mic preamps, this mixer is also at home in the studio.

The Behringer X32 Compact digital mixer boasts massive I/O for its compact size. Fitted with 16 great-sounding programmable mic preamps, eight XLR outputs plus six additional line I/O, two headphone connectors, and a talkback section with an integrated or external mic, the X32 Compact lets you do sizable shows without the fear of running out of I/O. A built-in expansion port for audio interface cards or digital networking bridges expands the X32 Compact's functionality as needed. Got a really big show coming up? The Behringer X32 Compact has a ready 48-channel digital snake via two AES50 ports that feature Klark Teknik's SuperMAC networking capability for ultra-low jitter and latency.

Eight true-stereo multi-effects processors

The Behringer X32 Compact digital mixer sports an onboard virtual FX Rack that gives you access to eight true-stereo (16 mono) multi-effects processors including delay, chorus, and dynamics. It can also run four studio-quality stereo reverbs together with eight channels of 31-band graphic EQ. Say goodbye to bulky, expensive outboard hardware!

Great-sounding Midas-designed mic preamps

For the design of X32 Compact's programmable preamps, Behringer worked with sister companies Midas and Klark Teknik to develop programmable, studio-grade mic preamps that deliver enhanced dynamic range, superior common mode rejection, and vanishingly low harmonic distortion (THD). These preamps sound amazing!

Instant compatibility with major DAWs

Behringer X32 Compact digital mixer's X-USB interface lets you record your tracks straight into your DAW. How convenient is that? Right out of the box, you get compatibility with ProTools, Logic, Cubase, Studio One, and nearly any other ASIO or Core-Audio compatible DAW!

Behringer X32 Compact Digital Mixer Features:

• Auto Mix yields automatic gain sharing and mic ducking
• X-Touch integration allows direct control of parameters over Ethernet
• Set up a full crossover without using a matrix mix
• Reverse polarity on your outputs for easy speaker alignment
• Redesigned Behringer X32-Edit app features a new interface, full screen capabilities, floating windows, configurable fader layers, and more
• 40-input, 25-total-bus digital mixer
• 16 mix buses, Main LCR, 6 matrix buses
• 16 programmable Midas-designed mic preamps deliver audiophile sound quality
• Highly configurable, with 40 input channels and 17 motorized faders
• 6 matrix mix buses, 16 mix buses feature inserts, 6-band parametric EQs and dynamics

Tech Specs

• Type:Digital
• Channels:40
• Inputs - Mic Preamps:16 x XLR
• Phantom Power:16 x Channels
• Outputs - Main:8 x XLR, 2 x 1/4" TRS (monitor)
• Outputs - Digital:1 x XLR (AES)
• Send/Return I/O:1 x Dual RCA Stereo (aux in), 6 x 1/4" TRS (aux in), 1 x Dual RCA Stereo (aux out), 6 x 1/4" TRS (aux out)
• Busses/Groups:25 total (16 x bus, main LCR, 6 x matrix)
• Inserts:Yes
• Talkback:1 x XLR
• MIDI I/O:In/Out
• Data I/O:1 x Ultranet, 2 x AES50, 1 x Ethernet
• Headphones:2 x 1/4" TRS (stereo)
• USB:2 x Type B, 1 x Type A
• Computer Connectivity:USB
• I/O Expansion Slots:1 x slot (32-channel USB audio interface)
• Faders:17 x 100mm (motorized)
• A/D Resolution:24-bit/48kHz
• EQ Bands:4-band EQ (channel strip), 6-band EQ (mix bus)
• Effects:Yes
• Signal Processing:Gate, Compressor
• Features:1 x 4-pin (lamp)
• DAW Control:Yes
• Screen:7" Color TFT (main), LCD with RGB Color Backlight (channel)
• Power Source:Standard IEC AC cable
• Height:8.5"
• Depth:20"
• Width:24.6"
• Weight:33.9 lbs.
